high efficiency waste tire pyrolysis plant
Basic Info
Model No.: LJ-10
Product Description
high efficiency waste tire pyrolysis plant
Introduction of background:
As tire has been used for all automotive industry widely, it has now become a significant problem of how to deal with waste tires after being used. As tire itself is a pollution to the environment, so it is urgent to handle those waste tires without pollution by high technology treatment.
Therefore, this project, which can recycle waste tyres into fuel oil without any pollution is of great meaning.
1. Model of high efficiency waste tire pyrolysis plant :
Model | Reactor size | Material | Handling capacity | Weight | Seaworthy packing |
LJ-8 | 2200*6000mm | Q245R boiler Steel plate | 5 tons | 24tons | 2*40HQ |
LJ-9 | 2200*6600mm | Q245R boiler steel plate | 8tons | 26tons | 2*40HQ |
LJ-10 | 2600*6600mm | Q245R boiler steel plate | 10tons | 30tons | 1*40FR+1*40HQ |
2. Working process Of high efficiency waste tire pyrolysis plant :
First, the raw materials are put into the reactor, and then seal the feeding in door, later start the machine and the reactor will be rotating and heated by coal, natural gas, wood or electricity. When the temperature reaches the degree of 250 to 280, we will get the crude oil, the oil steam will be continuous produced until the temperature reaches 350-460°C; oil steam will flow through oil gas separator, light component will enter the condensers and meanwhile the heavy oil will be discharged automatically into in heavy oil tank. The liquefied part will be condensed as crude oil, and the part which cannot be liquefied will be transferred by the water seal back to the burning chamber to be reused as heating material.
3. End of Product from high efficiency waste tire pyrolysis plant:
NO. Name Percentage Usage 1 Tyre oil 40%~45% * can be sold directly as fuel. * can be refine to diesel and gasoline by oil distillation plant 2 Carbon black 37% * can be sold directly. * can be refined by carbon black processing machine to make it finer (1500mesh finer). *can be made into pellet by pellet machine 3 13% *can be sold directly as steel or iron. 4 Waste gas 5% * can be recycled to heat up the reactor
4. Installation: We will be in charge of arranging our engineer to go to your place to guide the installation and train your workers how to operate thehigh efficiency waste tire pyrolysis plant ,and you will be in charge of the food, accommodation and round air tickets.
5. Land requirement: 300sq meters(10m*30m)
6. Exporting Experience:
America: Brazil, Canada, Colombia, USA, Middle East: Dubai, Iran, Jordan, Saudi Arabia, Turkey Europe: Albania , Bosnia and Herzegovina Asia: Afghanistan, India, Malaysia, Pakistan, Philippines, South Korea, Vietnam, Myanmar Africa: Ghana, Mozambique, Zambia
Contact us if you need more details on Tire Oil Extraction. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Tire Oil Extraction by Pyrolysis、Tire Pyrolysis Plant to Oil. If these products fail to match your need, please contact us and we would like to provide relevant information.
Product Categories : Waste Tire Pyrolysis Plant
